SG19 Stone & Sieve Grab

Material Handling and Sorting Grab for Excavators

The Engcon SG19 stone & sieve grab is designed for excavators weighing 12–16 tons, providing a reliable solution for material handling, sorting, and site clean-up tasks.

Part of Engcon’s SG series, the grab delivers strong gripping force while maintaining precise control, particularly when used with Engcon tiltrotators. For compatible machines, the EC-Oil automatic quick hitch system allows hydraulic connections to be made automatically without the operator leaving the cab.*

This makes the SG19 well suited for tasks such as handling rail materials, sorting scrap or ballast, and general attachment work around rail and civil projects.

Built for durability, the grab features reversible wear bars on the claws, reinforced joints with expander bushings, and a load valve with pressure accumulator that maintains gripping force during lifting operations.



SG19 provides clear operational advantages, including:

• Strong gripping capability for material handling and sorting
• EC-Oil automatic hydraulic connection system*
• Reversible wear bars on grab claws for longer service life
• Load valve and pressure accumulator maintaining gripping force
• Expander bushings in major joints for durability
• Bolt-on bracket system for easy bracket changes
• Complies with European safety standards


Note: Engcon sorting grabs deliver the best performance when used with a tiltrotator, allowing precise positioning and improved handling of materials. Operators should consider the loads applied to the tiltrotator and ensure the attachment is used within the recommended operating limits.

Available Options

The SG19 grab is designed for excavators in the 12–16 ton class and can be configured with additional accessories depending on the application.

Accessories

• Tooth kit for improved grip when handling difficult materials
• Closed sides to convert the grab into a grab bucket

* EC-Oil automatic quick connection applies to grabs with S40–S80 top brackets.

Integration & Support

Harrybilt Engineering supplies and supports Engcon attachments with a focus on correct machine configuration and integration with tiltrotator systems.

Our team can assist with selecting compatible attachments, configuring quick hitch systems, and ensuring the attachment suits your machine and working environment.
